Vacuum pump 14650-7T401 14650-7T40A DATSUN TRUCK D21/CIVILIAN W40/W41Part Name: Brake/Alternator vacuum pump, Brake booster pump, Vacuum pump Assy
Ref. Number: 14650-7T401
Models Applied: NISSAN
DATSUN TRUCK 1985/08-1997/01 D21
ELGRAND 1997/05-2002/05 E50
ATLAS 1992/01-2007/06 F23
TERRANO REGULUS 1996/08-2002/08 JR50
MISTRAL 1994/02-1997/05 R20
MISTRAL 1994/02-1997/05 R20
TERRANO 1995/09-2002/08 R50
CARAVAN/HOMY VAN 1993/05-2001/04 VE24
CIVILIAN 1982/08-1999/02 W40
CIVILIAN 1999/02- W41
CARAVAN/HOMY COACH 1993/05-2001/04 WE24
Engine: TD27 /TD27TI / QD32ETI / TD42 / QD32
Condition: Brand new Aftermarket high quality part
Features: Customized order is available , based on drawings/samples.
What is vacuum pump?Vacuum pumps are used in vehicles where the necessary vacuum cannot be generated by the intake manifold, for example, direct injection and turbo engines with variable valve timing.
The pump generates a negative pressure of between 750 and 850 mbar by drawing air out of the vacuum system. The pump works through positive displacement to move air from the vacuum system and then through the crankcase ventilation into the air intake system.
The vacuum pump is driven by the alternator rotor shaft. The Vacuum generated will be supplied to the high actuation force needed to control components such as:
- Brake boosters; Secondary air valves; Exhaust gas recirculation (EGR) valves; Turbocharger controls; Central locking systems
